Fun up and down your trails.

Our alloy lineup that will get you up and down your favorite mountain trails. The Wiki, Abajo, and Cascade all feature the same high-end aluminum alloy frame, the difference is in the build spec in order of good, better, best.

WIKI, ABAJO, CASCADE // LAUNCH VIDEO

“FUN UP AND DOWN YOUR OWN TRAILS”

CHOOSE YOUR BUILD

The Wiki, Abajo, and Cascade have all new components. Build your custom fit bike now with builds starting at $1849.

BUILD YOUR BIKE

REVIEWS

The best spec for the price.

Our look at the details suggest that the company has done their homework.

I realized how deeply in touch Fezzari is with what riders want and what the industry needs.

You can pick the bike up and hit the trails right away. It just has nice stuff on it.

A great bike, at a great price, with great components.

The Abajo has great components that are ready to perform and last under harder conditions.

See customer reviews

Frame Design

ALUMINUM ALLOY WITH ULTIMATE STRENGTH

DESIGN

Our Tetralink suspension design gives an incredibly plush ride while maintaining pedal efficiency. This leads to great small bump sensitivity while preserving mid-stroke support.

COMPATIBILITY

WHEELS FOR ANY TRAIL

COMPATIBILITY

The TetraLink suspension design combined with our GA-Link Geometry allows you to adjust the geometry for both 27.5 plus and 29er wheels.

ADAPTABLE

SPECS FOR EVERY LEVEL OF RIDER

ADAPTABLE

Our mid travel alloy lines has been designed to be adaptable for a wide range of riders, budgets, and skills levels. All models come with our lifetime warranty.

Tried and True

PROOF IS IN THE PUDDING

Tried and True

The Wiki, Abajo, and Cascade have room for any level or rider. More miles, trails, and experiences have been had on this model than any other mountain bike in our line up. Rest assured, you'll love your ride.

GEOMETRY

LET'S GET DOWN TO THE NITTY GRITTY

S M L XL
Top Tube 564 590 619 648
Seat Tube 400 420 457 495
Chainstay 434 434 434 434
Head Angle 66.4° 66.4° 66.4° 66.4°
Seat Angle 75° 75° 75° 75°
Head Tube 100 105 110 120
Bottom Bracket Height 342.9 342.9 342.9 342.9
Bottom Bracket Drop 34 34 34 34
Wheelbase 1135 1162 1192 1222
Standover Height 749.3 754.4 767.1 767.1
Stack 605 610 614 623
Reach 410 435 463 489
S M L XL
Top Tube 561 588 616 645
Seat Tube 400 420 457 495
Chainstay 432 432 432 432
Head Angle 66.9° 66.9° 66.9° 66.9°
Seat Angle 75.5° 75.5° 75.5° 75.5°
Head Tube 100 105 110 120
Bottom Bracket Height 342.9 342.9 342.9 342.9
Bottom Bracket Drop 22 22 22 22
Wheelbase 1135 1162 1192 1222
Standover Height 741.7 746.8 764.5 772.16
Stack 605 610 614 623
Reach 410 435 463 489
UNITS:
  • in
  • mm

Build Specs

MODEL

Wiki

$1,599.00

Abajo

$1,999.00

Cascade

$2,999.00

FRAMESET
FRAME
Fezzari Racing Design Alloy, 130mm travel, full sealed cartridge bearings, replaceable derailleur hanger, tapered headtube, water bottle bosses
Fezzari Racing Design Alloy, 130mm travel, full sealed cartridge bearings, replaceable derailleur hanger, tapered headtube, water bottle bosses
Fezzari Racing Design Alloy, 130mm travel, full sealed cartridge bearings, replaceable derailleur hanger, tapered headtube, water bottle bosses
FORK
X-Fusion RC32 29er, 130mm, Air, Boost 110x15mm thru axle
DVO Diamond D3, 140mm travel, 1.5 inch tapered steer tube, 110mmx15mm boost thru axle, black
DVO Diamond D1, 140mm travel, 1.5 inch tapered steer tube, 110mmx15mm boost thru axle, black
REAR SHOCK
Custom tuned X-Fusion O2 Pro RL, lockout, rebound adjust
Custom tuned X-Fusion O2 Pro RL, lockout, rebound adjust
Fox Float DPS, Performance Series, 3 Position Lever with Evol SV aircan, matte black
SIZES
S, M, L, XL
S, M, L, XL
S, M, L, XL
HEADSET
FSA Orbit 1.5 ZS No.57E, internal sealed cartridge bearing, tapered
FSA Orbit 1.5 ZS No.57E, internal sealed cartridge bearing, tapered
FSA Orbit 1.5 ZS No.57E, internal sealed cartridge bearing, tapered
DRIVETRAIN
SHIFTERS
SRAM SX Eagle 1x12
SRAM NX Eagle 12 Speed
SRAM GX Eagle Trigger 12-speed
FRONT DERAILLEUR
N/A
N/A
N/A
REAR DERAILLEUR
SRAM SX Eagle 1x12
SRAM NX Eagle 12 Speed
SRAM GX Eagle 1x12, X-HORIZON, 12-speed, Type-3 roller bearing clutch, long cage
CASSETTE
SRAM SX PG-1210 11-50t, 12-speed
Sram NX PG-1230 11-50t, 12-speed
SRAM XG-1275 GX Eagle, 10-52t, 12-speed
CRANK
SRAM SX Eagle Crankset 12-Speed Power Spline Spindle Interface
SRAM 1000 Eagle DUB
Truvativ Descendant DUB 6K Aluminum Eagle Crankset
CHAINRINGS
SRAM X-Sync, 32t Direct Mount
SRAM X-Sync, 32t Direct Mount
SRAM X-Sync, 32t Direct Mount
BOTTOM BRACKET
SRAM Power Spline 118/73
SRAM DUB, English Thread
SRAM DUB, English Thread
CHAIN
SRAM SX Eagle 12-speed
SRAM NX Eagle 12 Speed
SRAM GX Eagle 12-speed
COCKPIT
HANDLEBARS
Fezzari Trail mid-rise bar, 25mm rise, 31.8mm diameter, 780mm width, double butted 6061 alloy, black
Fezzari FRD Charger35, alloy, 35mm clamp, 780mm wide, 25mm riser, 9 degree back-sweep, 5 degree upsweep
Fezzari FRD Charger35, alloy, 35mm clamp, 780mm wide, 25mm riser, 9 degree back-sweep, 5 degree upsweep
STEM
Fezzari 3D forged 31.8mm alloy, 7 degree, 4-bolt bar clamp (customized sizing through 23-Point Custom Setup)
Fezzari FRD Charger35, alloy, 35mm clamp, sizes vary depending on custom fit
Fezzari FRD Charger35, alloy, 35mm clamp, sizes vary depending on custom fit
TAPE/GRIPS
Velo MTB grip, black, double density Kraton
Fezzari lock-on grips
Fezzari lock-on grips
SADDLE
WTB Volt Comp
Selle Italia Model-X
Selle Italia Model-X
SEAT POST
Fezzari Alloy, Dual Bolt Clamp, 31.6 x 350-400 (based on custom setup), Dropper seatpost available after adding bike to cart
Fezzari Alloy, Dual Bolt Clamp, 31.6 x 350-400 (based on custom setup), Dropper seatpost available after adding bike to cart
X-Fusion Manic Internal Dropper with Remote (Travel adjusted with 23-point customs fit after checkout)
PEDALS
Available Separately
Available Separately
Available Separately
WHEELS
RIMS
WTB i35 27.5+, 584x35c, TCS Tubeless Ready, 32 Hole
WTB I29 TCS 2.0 29er, Tubeless Ready, 32 Hole
Stans Flow 29er S2, Tubeless Ready, 32 hole
HUBS
Front: Bear Pawls Sealed Bearing Disc Boost 110x15mm, Rear: Bear Pawls Sealed Bearing Disc Boost 148x12mm HG Driver
Front: Bear Pawls Sealed Bearing Disc Boost 110x15mm, Rear: Bear Pawls Sealed Bearing Disc Boost 148x12mm, HG Driver
Front: Bear Pawls Sealed Bearing Disc Boost 110x15mm, Rear: Bear Pawls Sealed Bearing Disc Boost 148x12mm, XD Driver
SPOKES
1.8mm (15g) black stainless steel, brass nipples
1.8mm (15g) black stainless steel, brass nipples
1.8mm (15g) black stainless steel, brass nipples
TIRES
Maxxis Rekon 27.5x2.8 3C Exo Maxx Terra Tubeless Ready 120 TPI
Front: Maxxis Minion DHF 29x2.5 WT Exo/Tubeless Ready 60 TPI, Rear: Maxxis Aggressor 29x2.5 Exo/Tubeless Ready 60 TPI
Front: Maxxis Minion DHF 29x2.5 WT Exo/Tubeless Ready 60 TPI, Rear: Maxxis Aggressor 29x2.5 Exo/Tubeless Ready 60 TPI
TUBES
Maxxis 27.5x2.8/3.0, Tubeless setup available after adding bike to cart
Maxxis 29x2.5, (Tubeless setup available at Checkout)
Maxxis 29x2.5, (Tubeless setup available at Checkout)
BRAKES
BRAKES
Tektro HD-M276 Hydraulic Disc 180/160mm Rotor
SRAM Level Hydraulic Disc, SRAM Centerline Rotors, 180mm/160mm F/R
SRAM G2 R Hydraulic Disc, SRAM Centerline Rotors, 180mm/160mm F/R
BRAKE LEVERS
Tektro HD-M276
SRAM Level
SRAM G2 R
EXTRAS
EXTRAS
Fezzari Neoprene chainstay protector
Fezzari Neoprene chainstay protector
Fezzari Neoprene chainstay protector

SUPPORT

What's the difference between the Wiki, Abajo, and Cascade models?

The Wiki, Abajo, and Cascade Peak are Fezzari’s premiere aluminum alloy full-suspension bikes. All three models feature the same high-end alloy frame, the difference between them is the components. In short, the Wiki, Abajo, and Cascade could be viewed as ‘good, better, best’ options when compared to each other in their given category. Full spec differences are listed under ‘Build Specs’ above.

What is the warranty/guarantee?

Every Fezzari comes with a lifetime warranty on the frame.

How will my bike arrive to me?

All Fezzari bikes go through our 23-Point Custom Setup making sure the bike is fit and tuned specifically to you. They are test-ridden before delivery. If your bike is shipped to you, it's still tuned and ready to ride and requires just a couple of minutes of assembly.

Can a water bottle fit inside the frame?

All sizes can fit one water bottle inside the front triangle. Our Fezzari Dual Entry Bottle Cage and Fezzari Water Bottle are available to add to your bike at checkout.

Can I run a dropper post?

Yes! The Cascade Peak includes a dropper post and the Abajo and Wiki have cable routing for an internally routed dropper post. The option to add a dropper post is available at checkout on these models. The advantages of a dropper post are on-the-fly saddle height adjustment at the push of a button. It allows you to lower the seat when descending for more confidence and control while at the same time allowing you to raise the saddle back up for pedaling sections without ever getting off the bike. It also makes it easier to get on and off the bike since you can lower the saddle before mounting the bike.

Can I have the bike set up tubeless? What are the advantages of a tubeless set-up?

Yes! The option to add a tubeless set-up is available at checkout. The advantages of a tubeless set-up are increased flat protection from punctures and the ability to run a lower tire pressure for increased comfort and traction on the trail.

29er or 27.5+ tires? What’s the difference?

The Cascade, Abajo, and Wiki can accept both 29er and 27.5+ tires, making them highly versatile. 29er tires have a larger diameter than 27.5+ tires. In contrast, 29er tires are narrower than 27.5+ tires. In terms of on-trail feel, 29er tires offer a more precise, point-and-shoot feeling and provide better rollover capability over trail obstacles due to their larger diameter. 27.5+ tires have a more playful demeanor and feel more nimble. Their extra width allows for increased plushness and extra traction. This lends to a very confidence-inspiring ride for less experienced riders or someone who prioritizes playful handling.

What is the bottom bracket spec?

The Cascade, Abajo, and Wiki use a 73mm BSA English thread bottom bracket. Our philosophy is simple, if the bike is intended to be ridden on dirt, it gets a threaded bottom bracket. Threaded bottom brackets are easier to service and maintain.

What is the headset spec?

Top: ZS44; Bottom: ZS56.

What are the dropout dimensions and axle spec?

Rear Dropout: 12mm x 148mm spacing, Rear Axle: 174mm length | M12 x 1.0P | 20mm thread length, Front Dropout: 15mm x 110mm spacing, Front Axle: Per fork manufacture

What is the maximum tire clearance?

Rear Tire: 29in x 2.5in or 27.5in x 2.8in., Front Tire: Per fork manufacturer. (Typically 29in x 2.6in or 27.5in x 2.8in.)

What derailleur hanger is used on the Cascade, Abajo, and Wiki?

The SRAM Universal Derailleur Hanger (UDH) derailleur hanger is used on these models. A hanger can be purchased directly from Fezzari.
